Flanged Segment Ball Valve

Flow Control: On-off Control / Regulation Control (Approximately Equal Percentage)
Flow Direction: Unidirectional
Size Range: DN15~DN500
Pressure Rate: PN10-PN40; 150LB -300LB
End Connection: Flange
Face-Face Standard: ASME/ISA 75.08.02, IEC 60534-3-2
Materials: WCB, SS, etc
Seal Type: Metal Seat and Soft Seat
Leakage Standard: IEC 60534-4/ANSVFCI70.2
Metal Seat: Class V, VI
Soft Seat: Class VI
Working Temperature: -29-220℃，-29-350℃，-29-600℃
Suitable Medium: Solid, Liquid and Gas
Applicable Industry: Lithium battery, Pulp and Paper, Ferment, Chemical, Mining, and Sewage Treatment, etc
