Two-way Globe Valve
Categories: Regulating Valve Sort
Exhibitor Information
Binoww Fluid Control (Hebei) Co., Ltd.
Two-way Globe Valve
For flow and temperature control in heating, ventilation, and air conditioning (HVAC), industrial heating/cooling, and refrigeration systems.
Design
Balanced plug design — the optimised flow path offsets the differential pressure across the plug, reducing actuator torque for stable modulation.
Cage-guided plug with integrated seat — reduces flow-induced vibration, delivering reliable sealing and long service life.
Applications
HVAC · industrial heating/cooling · refrigeration systems
Standards & Specifications
Item Specification
Media: Chilled water, hot water, -10°C to +120°C
Connection Flanged, EN 1092-2 PN16
Size range DN40–DN300 (1¼"–12")
Max. working pressure: 1.6 MPa (232 psig)
Body material: Ductile iron, coated sand casting; paint or powder coating optional
Plug leakage ≤ 0.01% of Kvs; on/off and modulating control
Test standard ISO 5208
Key Features
Balanced plug — lower actuator torque, stable modulation
Cage-guided plug with integrated seat — reduced vibration, reliable sealing, long service life
V-ring packing gland with spring-loaded self-compensating mechanism
Flow characteristic curve
Body: coated sand casting; plug: silica sol investment casting
Full-bore design
For flow and temperature control in heating, ventilation, and air conditioning (HVAC), industrial heating/cooling, and refrigeration systems.
Design
Balanced plug design — the optimised flow path offsets the differential pressure across the plug, reducing actuator torque for stable modulation.
Cage-guided plug with integrated seat — reduces flow-induced vibration, delivering reliable sealing and long service life.
Applications
HVAC · industrial heating/cooling · refrigeration systems
Standards & Specifications
Item Specification
Media: Chilled water, hot water, -10°C to +120°C
Connection Flanged, EN 1092-2 PN16
Size range DN40–DN300 (1¼"–12")
Max. working pressure: 1.6 MPa (232 psig)
Body material: Ductile iron, coated sand casting; paint or powder coating optional
Plug leakage ≤ 0.01% of Kvs; on/off and modulating control
Test standard ISO 5208
Key Features
Balanced plug — lower actuator torque, stable modulation
Cage-guided plug with integrated seat — reduced vibration, reliable sealing, long service life
V-ring packing gland with spring-loaded self-compensating mechanism
Flow characteristic curve
Body: coated sand casting; plug: silica sol investment casting
Full-bore design
